Driver for integrating Home Manager IP X8, R12 and E28 modules directly with ELAN, without the Smart Center, over the local network.
The communication driver finds the modules on the network and automatically installs the output and input drivers for each one. Input and output actions are stored in the modules themselves, which makes the solution robust: if the controller or the network fails, the lighting keeps working.
Features
- Automatic discovery of IP modules on the local network
- Output and input drivers installed automatically for each module
- On/off outputs with status feedback, and dimming on the X8
- Shades and blinds with open, close and stop
- Press and long-press events from the inputs, configurable as push button or switch
- Analog input for a temperature or light sensor
- Actions stored in the modules: the lighting works even without the controller or network
Requirements
- Modules powered on and on the same subnet as the ELAN controller
Release notes
- 2026.10.15
Licensing library update. Dimming on the X8 outputs.
- 2025.12.05
New architecture: a communication driver that installs the drivers for each module, support for the E28 module and input configuration from the driver.
